c) Once the crosshead is repositioned clear of the limit stop, move the limit stop to the desired position
on the load frame.
Loosen the stop by turning counterclockwise, move to the desired position, and then tighten by
turning clockwise.
Position the Crosshead
1. Ensure that the computer and load frame are on and that TWX is running.
68 | MTS Criterion
™
Series 40
Running the Example Tension Test
