Typical Criterion Series 40 Load Frame Components
Description Name Item
Test area found only on MTS Criterion Series 40 dual
zone test space models. Upper Test Space 1
Rod on which limit stops are fastened. Limit Rod 2
Sets the upper limit of travel. The interlock is set when
this limit is reached. Upper Limit Stop 3
Moves with the crosshead and sets an interlock when
it comes into contact with a limit stop. Limit Switch Actuator 4
Lights when interlocks are cleared and the load frame
is ready for use. System Enabled Light 5
Warning :
The System Enabled light indicates that
crosshead movement can occur due to
control inputs or a test run in progress.
Unexpected crosshead movement can
cause equipment damage or injury.
Keep body parts out of the crush zone
and use caution whenever the System
Enabled light is lit.
Stops crosshead motion and sets an interlock when
pressed. Twist to reset. Emergency Stop 6
When enabled, allows you to control crosshead
motion. Handset 7
Turns the controller and load frame on and off. Power Switch 8
The power cord plugs into this connector. Power Input Connector 9
Electronics that serve as the interface between the
MTS TestSuite software and the load unit. Controller 10
Sets the lower limit of travel. The interlock is set when
this limit is reached. Lower Limit Stop 11
Provides a stable foundation for the load frame and
houses the controller and crosshead motor. Base 12
