Basic Operation
Operation of the hydraulic wedge grips consists of the following:
•
Determine the minimum required specimen gripping pressure to accommodate a specific specimen and
testing application.
•
Select the appropriate wedges.
•
Load a specimen into the grips.
About Grip Controls
The grip controls are located on the front panel of a load unit or on the front panel of an external hydraulic
grip supply.
Adjustment procedures for the hydraulic grip are supplied either in the load unit product manual or in the
hydraulic grip supply product manual.
Description
Item
Hydraulic Controls
1
Load Unit
2
78 Series 647 Hydraulic Wedge Grips Reference Manual
Operation
