MTS Series 647 Hydraulic Wedge Grips User Manual
Page 52
Environmental chambers that have U-plugs can be installed after the grips are installed. The following figure
shows the components used for most installations.
All-Temperature Grip Installation Components
Description
Item
Description
Item
Hydraulic Release
10
Shim Washer
1
Hydraulic Pressure
11
Connector Stud
2
Upper Grip Assembly
12
Environmental Chamber
3
Lower Grip Assembly
13
Water Supply
4
Hydraulic Release
14
Shim Washer
5
Hydraulic Pressure
15
Actuator Rod
6
Connector Stud
16
Load Unit Base Plate
7
Spiral Washer Set
17
Force Transducer
8
52 Series 647 Hydraulic Wedge Grips Reference Manual
Installation
