Grip water cooling configurations – MTS Series 647 Hydraulic Wedge Grips User Manual
Page 74
Description
Item
Description
Item
Increase Thickness
4
Connector Stud
1
Connector Stud
5
Medium Thickness
2
30 deg. (Do Not Exceed)
6
Decrease Thickness
3
Grip Water Cooling Configurations
Grip Water Cooling Assembly Configuration for Electromechanical
Frames
Cut hoses to required length at installation. MTS provides 48 ft (14.63 m) of hose (quantity 1) with the water
cooling assembly for conection to the water service.
Description
Item
Detail "A" - Applies to Pressure
A
74 Series 647 Hydraulic Wedge Grips Reference Manual
Installation
