MTS Series 647 Hydraulic Wedge Grips User Manual
Page 61
6. Install the cylinder assemblies and piston extensions.
Once the hydraulic chambers of the grips and the environmental chamber are installed, the cylinder and
piston extensions can be installed.
a) Lubricate the threads of the lower hydraulic chamber.
Description
Item
Description
Item
Socket Head Bolt
4
Upper Hydraulic Chamber
1
Cylinder Assembly
5
Environmental Chamber
2
Series 647 Hydraulic Wedge Grips Reference Manual 61
Installation
