Overview Reference
The MTS Series 647 Hydraulic Wedge Grips grasp and hold a specimen in place during testing, and provide
a constant, hydraulically actuated gripping force regardless of the applied test loads. The grips are specifically
designed for static or fatigue testing applications in MTS testing systems. A variety of wedges allow the grips
to be used to test a variety of materials. Optional equipment includes a cooling/warming kit and an external
hydraulic grip supply.
The size and shape of the Series 647 Hydraulic Wedge Grips vary among the models.
Grip Type
Item
Axial
1
Axial-Torsional
2
All Temperature
3
What you need to know
MTS Systems Corporation assumes that you know how to use your controller. See the appropriate manual
for information about performing any controllerrelated step in this manual’s procedures. You are expected to
know how to perform the following procedures:
