MAINTENANCE AND TROUBLESHOOTING
9. Movable Cutting Table Wheel Change Out:
NOTE: All four (4) Movable Cutting Table, Roller Wheels should be replaced at the same time (MK Diamond
Part No. – 133090)
(G)
Install Roller Wheel
Retaining Nut – Tighten
(F)
Lubricate Roller Wheels
(B)
Place Movable Cutting
Table On Work Bench
with Roller Wheels Up
(A)
Remove the Movable
Cutting Table
(C)
Remove Roller Wheels
(E)
Install Wheel/Washer Assembly
Into Movable Cutting Table
(D)
Prepare for Installation
Of New Roller Wheels
(H)
Install the Movable
Cutting Table
Roller Wheels
Rotate Wrench
Counter-clockwise
Clean Holes Roller Wheel 1/2-Inch Wrench
Rotate Wrench
Counter-clockwise
Washer
Lubricate with
Light Oil (WD-40,
3 in 1, etc)
Movable
Cutting Table
Movable
Cutting Table 1/2-Inch Wrench
