MK-2005G Revision 12/00, Effective Date December 26, 2000 Page 10
UNPACKING, TRANSPORT, UNIVERSAL STAND and ASSEMBLY
UNIVERSAL STAND:
Note: If using the MK Diamond, Universal Stand, perform the following steps.
1. Preparing to Seat Saw:
The MK-2000, Brick Saw weighs approximately 200 pounds; two people are required when lifting
or moving.
2. Seating the Saw:
3. Final:
(C)
Remove Water Basin
(B)
Position Water Pump
clear of Water Basin
(A)
Open the Universal Stand
and place on flat surface
(C)
Seat rear of Saw
on the back of the Stand
(B)
Seat front of Saw
on the front of the Stand
(A)
Orient the Saw
to the Stand
(C)
Reinstall Water Basin
Loosen Wing Nut
Pivot Up
Slide Water Basin
out back of Saw
Back of Stand Front of Stand
Front Brace Rear of Saw
Back of Stand
Slide Water Basin
in back of Saw
Back of Saw
