35
ITEM DESCRIPTION PART# OTY.
1 WASHER, 5/16 SAE FLAT 151754 4
2 WASHER, 1/4 SAE FLAT 151915 2
3 SHCS 5/16-18 X 3/4” 152444 2
4 WASHER, #10 SAE FLAT 154369 1
5 SCREW, FLAT HEAD 1/4-20 X 1/2 155812 2
6 SCREW, PAN HD PHIL 6-32 X 5/8 157393 4
7 WASHER, #10, INTERNAL TEETH 158336 1
8 BUSHING, SWITCH, 30 AMP 158799 1
9 SWITCH, 30 AMP MOTOR CONTROLLER 159488 1
10 PLATE, MOUNTING SWITCH 159489 2
11 LEVER, ON/OFF, 30 AMP SWITCH 159490 1
12 GASKET, COVER, 30 AMP SWITCH 159491 1
13 SEAL, LEVER, 30 AMP SWITCH 159492 1
14 SCREW, FLAT HD PHIL 6-32 X 5/16 159493 6
15 SCREW, PAN HD PHIL 10-24 X 5/16 159494 1
16 COVER, 30A SWITCH (COMP) 159539 1
17 LEVER, ACTUATOR (COMP) 159540 1
18 SCREW,HEX HD FL 10-24 X 5/16 159597 1
19 KEY, MOTOR MOUNT 159859 2
20 BOX, 30A SWITCH (COMP) 159865 1
21 MOTOR CORD 159907 1
22 POWER CORD 159908 1
23 PUMP CORD 159909 1
24 SWITCH BRACKET 165222 1
25 WIRE NUT 14/16 YELLOW 159968 1
MKDX PARTS LIST
