27
MKDX OPERATION
SHAPING
NOTICE
If you notice that the shape is of poor quality, despite having followed all the above instructions, check
the tightness of the clamps and sharpen the wheel with a sharpening stone.
DANGER
After your work and before disengaging the piece from the clamps, turn off the machine by means of
the power switch.
4. Proceed by pushing material slide toward shaping wheel and move material completely through
and pause (Figure 41).
5. Push material slide back in opposite direction completely through shaping wheel (Figure 42).
DO NOT force through!
6. For finishing of material, change shaping wheel to finer grit and repeat material shaping process.
Fig. 41 Move material through Fig. 42 Push in opposite direction
DANGER
While the machine is running, never reach into the shaping area. Bear in mind the instructions given in
the “Workstation” section (Page 20).
