24
MKDX OPERATION
CLAMPING THE MATERIAL
ADJUSTING FOR THICKNESS
1. Lower the clamps. The material must be firmly secured in place by a minimum of two clamps
(Figure 30).
2. Adjust height of clamp by loosening the nuts. You may remove or add washers to ensure a tight
fit (Figure 31).
Fig. 30 Lower the clamps
Fig. 31 Adjust height of clamps to ensure a tight fit
