41

MK-770 EXP PARTS LIST

Item

Description

Qty

Part #

A

Accessories

1

n/a

A1

Wrench, Blade Nut, 15/16 Boxed End

1

134684

A2

Wrench, Blade Shaft, 11/16 Open End

1

153450

A3

Blade, 7 x 5/8

1

-

A4

Owner’s Manual, 770EXP

1

160434

A5

Warranty Card

1

155037

A6

Assembly, Large Die Cast Rip Guide

A6A) Rip Guide (comp)

Rip Guide (raw)

A6B) Knob, Rubber (1/4-20x3/4)

1

1

1

1

n/a

159751

159751-RW

159428-1

A7

Carton, Accessory Pack

1

153366

A8

Sell Sheet, Tile Accessory

1

156915

A9

Clip, Table Lock, 50 deg

1

160331-3

A10

Clamp, Holding, Pump

1

162073

A11

Screw, Wing, 1/4-20x1/2

2

151888

A12

Nut, Hex, 1/4-20

2

151893

Table, Side (comp) - optional

1

160488

Table, Side (raw)

1

160485

Screw, Set, 10-32x3/8 - optional

2

160769

B

Assembly, Blade Guard, 7”

1

154811-MK

B1

Guard, 7” Blade (comp)

Guard, 7” Blade (raw)

1

1

154811

154810

B2

Elbow, 1/8 MNPT X 1/4 BARB 90° Brass

1

154652

B3

Knob, Davies

1

151681

B4

Washer, 5/16 SAE Flat

2

151754

B5

Wing nut, 5/16-18 Nylock

1

151746

C

Carton, MK-770 EXP

1

160433

C1

Carton, Outer (PCA# 3490003530)

1

160433-01

C2

Insert, Table Support (PCA# 3490003538)

1

160433-02

C3

Pad, Corner, Outer Carton (PCA# 3490003540

4

160433-03

C4

Insert, Outer Carton (PCA# 3490003531)

1

160433-04

C5

Insert, Accessory Pack (PCA# 3490003236, rev.A)

1

160044-03

C6

Divider, Cutting Head Carton (PCA# 3490003237, rev.A)

2

160044-01

C7

Carton, Cutting Head (PCA# 3490003234)

1

160044-05

C8

Divider, Cutting Head Carton (PCA# 3490003238, rev. A)

2

160044-02

C9

Pad, Carton, Cutting Head (PCA# 3490003355)

4

160044-08

D

Assembly, Cutting Head

1

160042

D1

Cutting Head (Comp)

Cutting Head (Raw)

1

1

159937

159936

D2

Helicoil, 3/8-16x3/8

1

153486

D3

Screw, Slotted Pan Head, 10-32x3/4

1

151750

D4

Screw, Slotted Pan Head, 10-32x1

1

151751

D5

Nut, Hex 10-32

2

151749

D6

Screw, Hex Head, 1/4-20x3/4

1

152370

D7

Nut, Hex, 1/4-20

1

151893

D8

Knob, Tri Plastic

1

156770-04

D9

Label, Warning, Read Owner’s Manual

1

155806

D10

Tag, Serial Number, Blank

1

157500

D11

Washer, Flat, 3/8

1

101360

D12

Drive Screw, Round Head, #7 x 5/16

2

157849

E

Frame

1

n/a

E1

Frame

1

153003

E2

Pan, Water

1

160121

E3

Clip, Cord, 1/4 Push Mount

2

157259

E4

Plug, Water Drain

1

159529

E5

Strap, 9" Drain Plug

1

159530

PARTS LIST:
