HCP

page 36

17.2 Humidity
User-calibration of the unit at the controller, using two humidity points:

RH 20

Humidity calibration at 20% relative humidity

RH 90

Humidity calibration at 90% relative humidity

Either a positive or a negative calibration correction can be applied to each selected calibration point.

General calibration instructions:

1.

Select the required calibration humidity in SETUP and set the corresponding calibration

correction to 0.0 °C.
2.

Measure the deviation from the selected calibration humidity under steady conditions, using a

reference

instrument.

3.

Set the calibration correction in SETUP. If the measured reference humidity is too low, the

calibration correction setting has to have a negative sign.

4.

Carry out a check measurement using the reference instrument.

5.

The procedure can be carried out for up to 2 calibration humidities.

Example: Humidity deviation at the load at 90% has to be corrected:

1.

Set calibration humidity in SETUP on RH 90 and set the corresponding calibration correction

to 0.0 %
2.

Using a calibrated reference instrument, an actual humidity of 88% is measured in normal

operation for a humidity setting of 90 %.
3.

In SETUP set calibration correction for RH 90 to -2.0 %

4.

The reference instrument should read 90.0% after the unit has settled down.

5.

An additional calibration can be programmed with RH 20 at 20% relative humidity.

rh 20

+3

%

rh 90

-2 %

factory

calibration

60%

40%

0%

20%

80%

100%
