HCP

page 28

40°C

34°C

ASF alarm

ASF activated

ASF activated

ASF aktiv

15°C

°C

ASF set to

+/-3°C in

SETUP

12.2.4 Automatic temperature monitor (ASF)
A monitoring device which automatically follows the selected temperature setpoint.

Automatic temperature monitor
OFF

(ASF OFF)

°C

MIN

AUTO

MAX

Using the push/turn control select
the symbol

AUTO

.

Hold down the SET key and select
off

using the push/turn control.

Automatic temperature monitor
ON

(ASF ON)

°C

MIN

AUTO

MAX

Using the push/turn control select
the symbol

AUTO

.

Hold down the SET key and select
on

using the push/turn control.

Notes on the ASF:

The tolerance margin for the ASF is selected in SETUP (see the menu item Tolerance margin ASF in the
section 10).

Tolerance margin reached = ASF activated
The ASF is automatically activated when the actual temperature has reached 50% of the selected tolerance
margin of the setpoint (in the example 37°C, -1,5°C).
The activation of the automatic temperature monitor is indicated by the bright symbol

AUTO

.
