pnt2
pnt2ta Activate output 2 above this point
pnt2tb Active output 2 below this point
pnt2ra Reset output 2 above this point
pnt2rb Reset output 2 below this point
sen1
s
Include Sensor 1 in Sum with other sensors “S”, individually
“I”, or not included “ ” (blank).
sen2
s
or " "
Include Sensor 2 in Sum with other sensors “S”, individually
”I”, or not included “ ” (blank).
sen3
s
or " "
Include Sensor 3 in Sum with other sensors “S”, individually
“I”, or not included “ ” (blank).
sen4
s
or " "
Include Sensor 4 in Sum with other sensors “S”, individually
“I”, or not included “ ” (blank).
duratn 0.00,
contIn
Active trigger Duration interval (seconds), or continuous.
Setting the duration to 0 causes the DS-3000 to be in
continuous mode, output is active whenever the threshold
conditions are satisfied.
Summary:
Contact output 2 can be used to control external equipment attached by means of
the provided removable wiring connector. Contact terminals are marked [COM --
common], [NO-- normally open] and [NC – normally closed]. The contact terminal
labels indicate the inactive contact state. Ie. [NO] contacts are OPEN when
inactive, but CLOSED when active. Both [NO] or [NC] contacts are referenced to
the [COM] or common terminal.
Outputs may be pulsed by selection of appropriate momentary contact duration,
or continuous. More details and examples programming these entries will be
given in the programming examples section, following later in this document.
8.2.6
Power Options Menu
Function:
Power Save and Power Control Options
Keystrokes:
Press menu until power is displayed, then up or down to reach each entry
tout
bat
S1 s2 s3 or s4
Time Out interval value. Press enter, and up, down to select
power save duration in minutes. Default is 0 for continuous
operation. On expiration of the time-out interval, the DS-3000
goes to sleep, shuts down attached sensors, and goes to a
lower power operational mode. The unit can be “awakened”
by pressing any front panel key.
Press enter to toggle between bat en (enabled) and bat “ “
(blank or disabled). If you have a battery option installed in
your DS-3000U the battery is set to enabled at the factory.
You should only use this option if you want to disable battery
power backup features or remove/disable the battery. Please
note that if you do not have the battery option installed, this
menu item has no effect regardless of setting
Press enter to toggle between on and off. “on” means the
sensor port is powered, and “off” means the sensor port is
unpowered. The factory default is to power all sensors
plugged in to the DS-3000U.
Summary:
Adjust the power save options.
