DS-3000U DS3000 User Guide
Loadstar Sensors, Inc. Page: 10 / 48 033-01419 Rev. 4
4 P HYSICAL D ETAILS
The following pictures of the DS-3000 Display module show the locations of all exterior connections, the user
interface, and the optional mounting base. Descriptions of each are in the following sections.
4.1 DS-3000 Physical Orientation
Figure 1: DS-3000 Top View - User Interface
Figure 2: Side View: Input Sensor Connectors
ENTER/TARE (enter)
UP/UNITS (up)
DOWN/FUNCTION (down)
SHIFT/MENU (menu)
O
pt
iona
l
Mo
un
tin
g
B
ase
Sensor 1 Sensor 2 Sensor 3 Sensor 4
