continue to hold down the enter button.
4. Release enter when the decimal point is at the desired position.
The display will retain this new decimal point selection until changed
again, or reset to the factory default.
Summary:
Manually changing the display precision.
8.2 Programming Mode Commands
Program mode is when the DS-3000 characteristics, responses and outputs are being changed by the
user. While in programming mode, the DS-3000 will not display load from attached sensors, it will
display a programming menu, summarized below, awaiting user commands. Once done editing, you’ll
need to leave programming mode and go back to run mode to see the results of any programming
changes you’ve made. The unit will not automatically “time out” and return to run mode once you’ve
entered programming mode.
8.2.1
Programming Command Summary
SHIFT
/MENU →
Å
U
P
/UNITS
DO
WN
/F
U
N
CT
ION
Æ
DspLay
tare
reLay1
reLay2
Power
oPtIon
run
dIsp1
tare 1
trgr1
trgr1
tout
led
dIsp 2
tare 2
pnt1
pnt1
bat
trgt
dIsp 3
tare 3
trgr2
trgr2
S1
v3 05*
dIsp 4
tare 4
pnt2
pnt2
S2
Pass
type
Sen1
Sen1S1
S3
Factor
Sen2
Sen2S2
S4
Sen3
Sen3S3
sen4
sen4s4
duratn
duratn
*Version: The actual version of the firmware is displayed (e.g. v3 05).
8.2.2
Display Options Menu
Function:
Display Source Select
Keystrokes:
Mode Key menu till dspLay is displayed, then press up or down buttons to
select your desired display mode, then press enter to change enabled/disabled
(decimal point lights when enabled).
dIsp1 ©
dIsp2 ©
dIsp3 ©
dIsp4 ©
Display connected Sensor 1
Display connected Sensor 2
Display Connected Sensor 3
Display Connected Sensor 4
Factory default is for all 4 displays to be on
