18. Install Fenders
Locate the Fenders, six (6) Self Drilling Screws, six (6)
1/4” X 1” Flat Washer and six (6) Lock Washers.
Measure 13” from the top of the C-Channel on the #5
U-Tube and mark the location. Use the self drilling screw
to pre drill the hole. Align the top hole of the fender with
the predrilled hole. Make sure the fender is level, now
mark corresponding holes on the side of fender on the #4
and #6
19. License Plate Installation
Using the existing holes in the Light bracket mount the license plate using hardware provided in Step 19 as shown
in the driver’s side of the trailer.
Self Drilling
Screws and 1”
Flat Washer
Fender
13”
