Lgt 1’ extension

2120 Naegele Road, Colorado Springs, CO 80904
LGT 1’ Extension
Accessory option for the LittleGiant Trailer™
Part No. ACC 3075
ACC3075rev0614
The 1’ Extension is a bolt together add-on, and
installs at the rear of the trailer.
The LGT Extension transforms the 7’ LittleGiant Trailer into an 8 foot long trailer by inside dimension. This is effectively
that of a full size pick up bed.
Manufactured by Let’s Go Aero in Colorado Springs, CO
Parts Overview
Qty Description
Tools Needed
1
Base Panel
2
Side Panels
2
Inside Frame Telescope Tube
2
Outside Frame Telescope Tube
2
C-Channel Extension
2
C-Channel Tie Plate
1
#9 U-Tube (Body Style)
1
#10 U-Tube (End Gate Style)
4
Pin Nut Assembly (5/16” x 1”fine thread bolt, lock washer and flat washer)
6
5/16” x 2” bolt
6
5/16” Split lock washer
6
5/16” Fender washer
12
K-Lath Phillips Tek screw
12
Star washer
12
1” flat washer
2
12” Wire Harness Extension with attached
butt connectors
2
1/2” Ribbed cable protector
2
3/8” Ribbed cable protector splice
2
Ring Connector
4
1/4” split lock washer
2
Zip tie
4
5/16” Spring Nut
Variable speed drill
5/16” socket
5/16” wrench
7/16” wrench
Philllips power bit
Wire Stripper/crimper
