Let's Go Aero LittleGiant Trailer LGT 1107 - T (Torsion based model) User Manual
Page 10
– 10 –
l
iTTle
G
ianT
T
railer
™
LGT11070614
Tools Needed
1/2” Socket Wrench
3/4” Socket Wrench
3/4” Box Wrench
1/2”Box Wrench
Lug Wrench
Phillips head and 3/8” Hex Nut Driver
#2 Phillips Screwdriver Bit
Wire Stripper
Drill for Self Drilling Screw
Description
Quantity
Step 12
5/16” x 1-3/4” Bolt
8
1/4” USS Flat Washer
16
5/16”
Lock
Nut
8
1” Endgate Support Bracket
4
Step 13
5/16” x 1-3/4” Bolt
8
1/4” USS Flat Washer
8
5/16”
Lock
Nut
8
2” Endgate Body Latch
4
Foam
Roll
2
Step 14
Snap
Pin
4
Step 15
Wire Harness (in Light Box)
1
Nylon Zipties (in Light Box)
6
Step 16
S/T/T Tail Lights Passenger Side (in Light Box)
1
S/T/T Tail Lights Driver Side (in Light Box)
1
Light
Bracket
2
5/16” x 1-3/4” Bolt
4
5/16”
Flat
Washer
8
5/16”
Lock
Nut
4
Ring
Terminals
2
Step 17
Side Marker Light Assembly
2
(Located in Light Box)
Step 18
Self
Drilling
Screw
6
1/4” X 1” Flat Washer
6
Lock
Washer
6
Step 19
10 X 3/4” Machine head screws
2
1”
Washers
4
Nylocks 2
Step
2
1/2”
X
3”
Bolt
4
1/2”
Flat
Washers
8
1/2” Nylon Lock Nuts
4
Step 3
Spring Nut, L-Bracket, Hardwares:
5/16” Spring Nut
2
1/2” Spring Nut
2
1/2” X 1” Bolt
2
1/2”Lock Washer
2
1/2” Flat Washer
2
5/16” X 2” Bolt
2
5/16” Flat washer
2
5/16” Split ring lock washer
2
Endgate L-Bracket
2
Spring Nut Holder
4
Step 4
1/2”
X
3”
Bolt
4
1/2”
Lock
Nut
4
1/2”
Flat
Washer 8
Step 5
1/2” X 3-1/2” Bolt
2
1/2” X 3” Bolt
2
1/2”
Lock
Nut
4
1/2” Flat Washer
8
Safety
Cables
2
Safety Cable Washers (Big)
2
Step 7
5/16”
X
4”
Bolt
12
5/16”
Flat
Washer
28
5/16”
Lock
Nut
14
5/16” x 2” Bolt
2
Endgate Support L-Bracket
2
Step 8
Pin Nut Assembly Kit:
5/16” x 1” Bolt
16
5/16” USS Flat Washer
16
Pin Nut
16
5/16” Internal Tooth lock washer
16
Step 10
Self
Drilling
Screw
12
1”
Flat
Washer
12
Star
Washer
12
Step 11
Self
Drilling
Screw
22
1”
Flat
Washer
22
Star
Washer
22
For ease of assembly, small hardware parts are kitted and marked by assembly step. Below is a description of parts and quantities:
(Extra hardware Provided for smaller fsatners and screws)
Description
Quantity
