Cam Designer Basic
Functions
Export of profile data
48 2.1 EN - 09/2005
L
7.10 Export of profile data
 Exporting the profile data to the controller via
– Drive PLC Developer Studio (Servo PLC and ECSEA).
– Global Drive Loader.
– Cam Loader.
Target system - Servo PLC, ECSEA and 9300EK servo cam

How to export the profile data:
1. The data must be compiled before being exported.
• For this purpose select ViewInterpolation Mode or click and then select Ed-
itStart of Calculation or press .
2. Select the corresponding slave axis in the »Cam Designer Basic« by means of dou-
ble-click.
3. Go to the interpolation mode and press the LCx file.
• If this function is executed for the first time, a dialog appears which is confirmed
with OK. The system now creates a file with the name of the slave axis and the
ending *.lc9 or *.lc7.
• Compiling must be repeated for new profiles, cam groups or position markers
and changes made.
• After every compiling, the data are transferred to the *.lc9-file or *.lc7-file.
The following two steps are only required for the Software Package - Cam Offline down-
load.
4. Double-click ResourcesCamSupport in the DDS.
5. Click Add Profile Data to Project .
• A dialog appears in which you can select the *.lc9-file.

Tip!
Do not forget to save your CamDesigner Basic project on hard disk or diskette, in
case you want to make subsequent changes. Select FileSave as... to save the
CamDesigner Basic project under a new name.

Note!
The 9300EK servo cam exclusively works with the Online download.
