5.5 Toolbar
The display is optional.
Via the icons of the toolbar you can easily execute some of the most frequently used menu
commands without making a detour via the Menu bar . The selection of the available func-
tions depends on the active mode/window.
 Simply click an icon to activate the corresponding command.
Icon Menu command Function
FileNew Creates a new Cam Designer Basic project.
FileOpen Opens a Cam Designer Basic project.
FileSave Saves the project under the current name.
FilePrint Prints the project.
EditCut Deletes a selected object and moves it to the clipboard.
EditCopy Copies a selected object and moves it to the clipboard.
EditPaste Pastes a copied or cut object into the current position.
EditUndo Undoes the last action.
EditRedo Redoes the last undone action.
ViewZoom In Enlarges the worksheet view.
ViewComplete View Resets the worksheet view to standard size.
Edit
Acceleration Dimensioning
Opens the acceleration dimensioning dialog.
File
Connect to OPC Server
Establishes a connection to the OPC server.
File
Create LCx-file and Download
Opens a dialog for selecting a drive.
DrawSelect Selects the drawing objects.
DrawLine Draws a line.
DrawPolynomial (5.) Draws a 5th grade polynomial.
DrawSloped Sine Draws a sloped sine function (Bestehorn).
DrawTable Draws a table.
ViewObject Input Mode Input of motion objects.
