Cam Designer Basic
Functions
The cam group
46 2.1 EN - 09/2005
L
7.9 The cam group
Select ViewEdit Cam in the »Cam Designer Basic« to take the bottom window (output ar-
ea) to the corresponding mode.
7.9.1 Defining the cam type and cam reference

Tip!
The cam group can either refer to the X axis or to the Y axis. The cam group func-
tions are available in the context menu of the right mouse button.

How to define the cam type and cam reference:
1. First, define the cam reference for the current data set under Cam for Slave Axis.
• Subsequent changes are not possible. The selected cam data will be deleted and
must be entered again.
2. The cam types for the individual tracks can be defined using the context menu of
the right mouse button.
• If you right-click in the track, you can directly change the came type.
3. Select Add New Cam to add a new cam to the corresponding track.
• You can add up to four cams to every track.

Note!
Only available for Software Package - Cam
The settings only apply to the product selected. For the other products, the set-
tings have to be repeated.
Position cam in positive effective direction
Position cam in negative effective direction
Position cam Both
Time-based cam in positive effective direction
Time-based cam in negative effective direction
