Cam Designer Basic
Operation
Open an existing project
34 2.1 EN - 09/2005
L
6.2 Open an existing project

Tip!
• It is possible to open several projects (worksheets) simultaneously in the »Cam
Designer Basic«. The commands for arranging the worksheets can be found in
the "Window" menu.
• With a click on the entries 1...4 in the File menu you can open one of the four
projects edited last.

How to open an existing project...
1. Click the symbol in the symbol bar or select FileOpen.
2. Select the corresponding project file (*.cam) in the dialog box Open.
3. Press the button Open .
• After this, the project worksheet will be displayed in the workspace.
6.2.1 Selecting the properties of a slave
The properties of a slave can always be changed.

How to change the properties of a slave...
1. Select the corresponding slave axes and select Properties of the slave axis from the
menu of the right mouse button.
2. Go to the Project settings dialog box and enter the new settings.
How to define the properties of the slave...
( 26)
3. Select OK to accept the settings and close the dialog box.
