1
About this documentation
1.2
Conventions used
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
1.2
Conventions used
This documentation uses the following conventions for highlighting different types of information:
Type of information
Identification
Examples/notes
Numbers
Decimal
Normal spelling
Example: 1234
Decimal separator
Point
In general, the decimal point is used.
Example: 1234.56
Hexadecimal
0x[0 ... 9, A ... F]
Example: 0x60F4
Binary
• Nibble
0b[0, 1]
Example: ’0b0110’
Example: ’0b0110.0100’
Text
Version information
Text colour blue
All pieces of information that only apply to or from a specific
software version of the controller are highlighted
correspondingly in this documentation.
Example:
This function extension is available from software
version V3.0!
Program name
» «
»PLC Designer«...
Window
italics
The message window... / The Options dialog box ...
Variable name
Setting bEnable to TRUE...
Control element
Bold
The OK button ... / The Copy command ... / The Properties tab
... / The Name input field ...
Sequence of menu
commands
If several commands must be used successively to carry out
a function, the individual commands are separated by an
arrow: Select File
Open to...
Shortcut
Use
If a key combination is required for a command, a "+" is
placed between the key identifiers: With
Hyperlink
Reference to further information: Hyperlink to further
information.
Icons
Page reference
Reference to further information: Page number in PDF file.
Step-by-step instructions
Step-by-step instructions are marked by a pictograph.
