4 Creating a backup & carrying out recovery
4.2 Carrying out restore and auto-restore
28
Lenze · Backup & Restore · Software Manual · DMS 1.3 EN · 04/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2 Carrying out restore and auto-restore
4.2.1 Carrying out a restore: on the Engineering PC (recommended variant)
[4-3] Illustration example: »Backup & Restore« under Windows XP (Engineering PC)

How to carry out a restore:
1. Connect a USB stick to the Engineering PC.
2. Start the »Backup & Restore« application.
3. Select the USB stick.
4. Open the Restore/Update tab.
5. Select the Restore action
6. Available backups are shown.
7. Select a backup.
Further information:  Components of the backup designation ( 22)
8. Press Start.
A control file is written to the USB stick.
9. Connect the USB stick to the controller on which you want to carry out the restore.

Note!
• Before a restore is performed, a safety backup is created.
• Remove (after carrying out the restore) the USB stick from the controller.
• Only applies to Windows embedded Standard: After a restore has been performed,
the file system is automatically checked (chkdsk.exe).
