Configuration
7-4 UONu_^MPMQ
L
Code IMPORTANT Possible settings Name Code IMPORTANT
Info Selection Lenze
Name
C007
*
Terminal
configuration
-0- E4 E3 E2 E1
-0- CW/CCWDC brakeJOG1/2/3
-1- CW/CCWPAR
JOG1/2/3
-2- CW/CCWQSP JOG1/2/3
-3- CW/CCWPAR DC brake JOG1
-4- CW/CCWQSP PAR JOG1
-5- CW/CCWDC brake Trip set JOG1
-6- CW/CCWPAR Trip set JOG1
-7- CW/CCWPAR DC brake Trip set
-8- CW/CCWQSP PAR Trip set
-9- CW/CCWQSP Trip set JOG1
-10- CW/CCWTrip set UP DOWN
-11- CW/CCWDC brake UP DOWN
-12- CW/CCWPAR UP DOWN
-13- CW/CCWQSP UP DOWN
-14- CCW/QSPCW/QSPDC brake JOG1
-15- CCW/QSPCW/QSP PAR JOG1
-16- CCW/QSPCW/QSPJOG1/2/3
-17- CCW/QSPCW/QSPPAR
DC brake
-18- CCW/QSPCW/QSP PAR Trip set
-19- CCW/QSPCW/QSPDC brake Trip set
-20- CCW/QSPCW/QSP Trip set
JOG1
-21- CCW/QSPCW/QSP UP DOWN
-22- CCW/QSPCW/QSP UP JOG1
D CW =
CW rotation
D CCW =
CCW
rotation
D DC brake =
DC injection
brake
D PAR =
Change of
parameter
sets
D JOG =
JOG
frequency
D QSP =
Quick stop
D Trip-Set =
External fault
D UP/DOWN =
Motor
potentiometer
functions
C008
¿
Function relay K1 -1- -0- Ready for operation
-1- TRIP fault message
-2- Motor is running
-3- Motor is running / CW rotation
-4- Motor is running / CCW rotation
-5- Field frequency f
d
= 0
-6- f
dset
reached
-7- Q
min
reached
-8- I
max
reached
-9- Overtemperature ( J
max
-10 °C)
-10- TRIP or Q
min
or IMP
C009
*
Device address 1 1 {1} 99 Only for LECOM
applications
C010 Minimum field
frequency
0.0 0.0 {0.1Hz} 480.0
C011 Maximum field
frequency
820X 50.0 30.0 {0.1Hz} 480.0
821X 50.0 7.5 {0.1Hz} 480.0
30.0 {0.1Hz} 480.0
(Software
2x)
(Software
1x)
822X/824X 50.0 7.5 {0.1Hz} 480.0
