Commissioning
5-2 UONu_^MPMQ
L
5.2 Short set-up (Factory setting)
5.2.1 Switch-on sequence
Step
1.Switch on mains voltage
The drive controller is ready for operation after approx.
2 seconds.
2.Select the direction of rotation. D CW rotation:
- Apply a LOW signal to terminal E4 (0...+3V).
D CCW rotation:
- Apply a HIGH signal to terminal E4 (+12...+30V).
3.Select the setpoint. Apply a voltage 0...+10 V to terminal 8.
4.Enable the controller. Apply a HIGH signal (+12...+30V) to terminal 28.
5.The drive is now operating according to factory
setting.
5.2.2 Factory setting of the most important drive
parameters
Setting Code Factory setting Adaption to
the
application
Operating mode C001 -0- Setpoint selection via terminal 8
Control via terminals
Parameter setting via 8201BB See the Code
Table
chapter 7.2
Terminal configuration C007 -0- E4 E3 E2 E1
CW/CCWDC injection brake JOG1/2/3
See the Code
Table
chapter 7.2
Machine data Chapter 5.3 ff.
Speed range Min. field frequency C010 0.0 Hz Chapter 5.3.1 Speed a ge
Max. field frequency C011 50.0 Hz
C apte 5 3
Acceleration
and
Acceleration time C012 5.0 s Chapter 5.3.2
and
deceleration
times
Deceleration time C013 5.0 s
Current limit
l
Motor mode C022 150 % Chapter 5.3.3 Cu e t t
values
Generator mode C023 80 %
C apte 5 3 3
Drive performance Chapter 5.4 ff.
Current,
torque,
power Operating mode C014 -4- Motor-current control Motor-current
control, see
chapter
5 4 2 1
power
characteristic V/f rated frequency C015 50.0 Hz
p
5.4.2.1
V/f
characteristic
V
min
setting C016 0 %
characteristic
control
D
with V
min
Slip compensation C021 0 %
D with V
min
boost, see
chapter
5.4.2.2
