Lenze 8210 series - Manual (Page 17)

Technical Data
UONu_^MPMQ 3-7
L
3.4 Fuses and cable cross-sections
3.4.1 Single drives with 150 % overload
qЬЙ н~ДдЙ о~дмЙл ~кЙ о~дбЗ Сзк нЬЙ зйЙк~нбзе зС UOuu ЕзенкзддЙкл ~л
лбеЦдЙ ЗкбоЙл пбнЬ ~ г~нЕЬбеЦ гзнзк ~еЗ NRM B зоЙкдз~ЗK
Type Mains input L1, L2, L3, PE/motor connection U, V, W, PE Type
Operation without mains filter/mains choke Operation with mains filter/mains choke
Fuse
F1, F2, F3
E.l.c.b. Cable
cross-section 1)
Fuse
F1, F2, F3
E.l.c.b. Cable
cross-section 1)
VDE UL VDE mm 2 AWG VDE UL VDE mm 2 AWG
8211 M 6A - B 6A 1 17 M 6A - B 6A 1 17
8212 M 10A - B 6A 1.5 15 M 6A - B 6A 1 17
8213 M 10A - B 10A 1.5 15 M 10A - B 10A 1.5 15
8214 - - - - - M 10A - B 10A 1.5 15
8215 M 16A - B 16A 2.5 13 M 16A - B 13A 2.5 13
8216 M 25A - B 25A 6 10 M 20A - B 20A 4 11
8217 M 32A - B 32A 6 10 M 25A - B 25A 6 10
8218 - - - - - M 32A - B 32A 6 10
1) Observe national and regional regulations (e. g. VDE/EVU)!
3.4.2 Single drives with 120 % overload
qЬЙ н~ДдЙ о~дмЙл ~кЙ о~дбЗ Сзк нЬЙ зйЙк~нбзе зС UOuu ЕзенкзддЙкл ~л
лбеЦдЙ ЗкбоЙл пбнЬ ~ г~нЕЬбеЦ гзнзк ~еЗ NRM B зоЙкдз~З бе ймгй
~еЗ С~е ÇêáîÉëK
Type Mains input L1, L2, L3, PE/motor connection U, V, W, PE ype
Operation with mains filter/mains choke
Fuse F1, F2, F3 E.l.c.b. Cable cross-section 1)
VDE UL VDE mm 2 AWG
8211 M 6A - B 6A 1 17
8212 M 6A - B 6A 1 17
8213 M 10A - B 10A 1.5 15
8214 M 10A - B 10A 1.5 15
8215 M 20A - B 20A 4 11
8216 M 20A - B 20A 4 11
8217 M 32A - B 32A 6 10
8218 M 32A - B 32A 6 10
1) Observe national and regional regulations (e. g. VDE/EVU)!
