3.2 Rated data
(Operation with 150 % overload)
3.2.1
Types 8211 to 8214
150 % overload
Type
8211
8212
8213
8214
Order no.
EVF8211-E
EVF8212-E
EVF8213-E
EVF8214-E
Mains voltage
V
rated
[V]
320 V - 0% ≤ V
N
≤510 V + 0% ; 45 Hz ¼ 65 Hz 0%
Alternative DC supply
V
DC
[V]
450 V - 0% ≤ V
G
≤ 715 V + 0%
Mains current
with mains filter/mains choke
without mains filter/mains choke
I
mains
[A]
I
mains
[A]
2.5
3.75
3.9
5.85
5.0
7.5
7.0
--
Data for mains operation with 3 AC/400 V/50 Hz/60 Hz; 450 V ≤V
G
≤ 650 V or
3 AC/460 V/50 Hz/60 Hz; 460 V≤ V
G
≤ 725 V
400 V 460 V 400 V 460 V 400 V 460 V 400 V 460 V
Motor power (4 pole ASM)
ff 4kH /8kH *
P
rated
[kW]
0.75
1.1
1.5
1.5
2.2
2.2
3.0
3.7
Motor power (4 pole ASM)
off 4kHz/8kHz*
P
rated
[hp]
1.0
1.5
2.0
2.0
2.9
2.9
4.0
5.0
Output power U, V, W
off 4 kHz/8 kHz*
S
rated8
[kVA]
1.6
1.9
2.7
3.1
3.8
4.3
5.2
5.8
Output power +U
G
, -U
G
1)
P
DC
[kW]
0.7
0.7
0.0
0.0
1.0
1.0
0.0
0.0
Output
t
4 kHz*
I
rated4
[A]
2.4
2.4
3.9
3.9
5.5
5.5
7.3
7.3
Output
current
8 kHz*
I
rated8
[A]
2.4
2.4
3.9
3.9
5.5
5.5
7.3
7.3
12 kHz*
I
rated12
[A]
2.0
1.9
3.3
3.0
4.6
4.3
6.1
5.7
16 kHz*
I
rated16
[A]
1.8
1.7
2.9
2.7
4.1
3.8
5.5
5.1
noise optimized
12 kHz*
I
rated12
[A]
1.9
1.8
3.1
2.9
4.4
4.1
5.8
5.4
noise optimized
16 kHz*
I
rated16
[A]
1.6
1.5
2.5
2.3
3.6
3.3
4.7
4.4
Max.
t t
4 kHz*
I
ratedmax4
[A]
3.6
3.6
5.9
5.9
8.3
8.3
11.0
11.0
a
output
current
8 kHz*
I
ratedmax8
[A]
3.6
3.6
5.9
5.9
8.3
8.3
11.0
11.0
current
for 60s
2)
12 kHz*
I
ratedmax12
[A]
3.0
2.8
4.9
4.6
6.9
6.6
9.2
8.7
for 60s
)
16 kHz*
I
ratedmax16
[A]
2.7
2.5
4.4
4.1
6.2
5.8
8.2
7.7
noise optimized
12 kHz*
I
ratedmax12
[A]
2.9
2.7
4.7
4.4
6.6
6.2
8.8
8.2
noise optimized
16 kHz*
I
ratedmax16
[A]
2.4
2.1
3.8
3.5
5.4
5.0
7.1
6.6
