Consignes de sécurité

Consignes de sécurité pour l’installation selon U

L

ou U

R

1

68

EDKCSEK002 DE/EN/FR 2.0

1.3

Consignes de sécurité pour l’installation selon U

L

ou U

R

Warnings!

General markings:

ƒ

Use 60/75 °C or 75 °C copper wire only.

ƒ

Maximum ambient temperature 55 °C, with reduced output
current.

Terminal tightening torque of lb-in (Nm)

Terminal

lb-in

Nm

X 23

10.6 ... 13.3

1.2 ... 1.5

X 26

4.4 ... 7.1

0.5 ... 0.8

Wiring diagram AWG

Terminal

AWG

X 23

12 ... 8

X 26

24 ... 12
