Mechanical installation

Mounting with fixing rails (standard installation)

Mounting steps

3

47

EDKCSEK002 DE/EN/FR 2.0

3.2.2

Mounting steps

How to mount the capacitor module:
1. Prepare the fixing holes on the mounting plate.

–

Apply a drilling jig for this purpose.

2. Take the fixing rails from the accessory kit in the cardboard box.
3. Push the rails into the slots of the heatsink:

–

From above: push in the long side.

–

From below: push in the short side.

4. Fix the capacitor module onto the mounting plate.
