Electrical installation

Power terminals

4

51

EDKCSEK002 DE/EN/FR 2.0

4.2

Power terminals

Stop!

No device protection if the mains voltage is too high
The mains input is not internally fused.
Possible consequences:

ƒ

Destruction of the device if the mains voltage is too high.

Protective measures:

ƒ

Observe the maximally permissible mains voltage.

ƒ

Fuse the device correctly on the supply side against mains
fluctuations and voltage peaks.

Stop!

The capacitor module is approved exclusively for operation on
symmetrical mains. Operation on external conductor-earthed mains
is not permissible.

ƒ

All power connections are plug connections and are coded. The
ECSZK000X0B connectors for capacitor modules must be ordered
separately.

ƒ

Installation of the cables in accordance with EN 60204-1.

ƒ

The cables used must comply with the approvals required at the site of
use (e.g. VDE, UL, etc.).

Terminal assignment

Terminal

Function

Electrical data

X23

Connection of DC-bus voltage

X23/+UG

Positive supply of DC-bus voltage

Application- and type-dependent
0 ... 770 V
up to 24.5 A (

44)

X23/+UG
X23/-UG

Negative supply of DC-bus voltage

X23/-UG
X23/PE

Connection to earth

X23/PE
