Mechanical installation

Mounting with fixing rails (standard installation)
Dimensions

3



46

EDKCSEK002 DE/EN/FR 2.0

3.2

Mounting with fixing rails (standard installation)

3.2.1

Dimensions



Note!

Mounting with ECSZS000X0B shield mounting kit:

ƒ

Mounting clearance below the module > 195 mm

h

h

a

g

g

a

d1

d

g

g

³

65mm

e

³

65mm

d1

d

b

b

0

1

ECSXK005

Fig. 3-1

Dimensions for ”panel-mounted” design

Capacitor module

Dimensions [mm]

Type

Size

a

b

d

d1

e

g

h

ECSEK001



88.5

240

276

260

176

6.5

(M6)

10

ECSEK002



131
