Electrical installation

Power terminals

Connection to the DC bus (+U

G

, -U

G

)

4

53

EDKCSEK002 DE/EN/FR 2.0

4.2.1

Connection to the DC bus (+U

G

, -U

G

)

ƒ

If the total cable length is > 20 m, install an axis module or a capacitor
module directly at the power supply module.

ƒ

Design the ±U

G

cables twisted and as short as possible. Ensure

short-circuit-proof routing!

ƒ

Cable length (module

module) > 30 cm: install shielded ±U

G

cables.

Fuses

ƒ

When using ECSxE power supply modules which are fused on the supply
side the DC-bus supply need not be fused.

ƒ

When ECS axis modules are supplied by devices of the 82xx or 93xx series
which can supply a continuous current > 40 A, use the following fuses
between the supplying device and the ECS devices:

Fuse

Support

Value [A]

Lenze type

Lenze type

50

EFSGR0500ANIN

EFH20007

Warnings!

ƒ

Use UL-approved cables, fuses and fuse holders only.

ƒ

UL fuse:
– Voltage 500 ... 600 V
– Tripping characteristic ”H”, ”K5” or ”CC”

Cable cross-section

Cable
length (mod
ule/module)

Wire end ferrule

Cable
cross-section

Tightening torque

Stripping length

Up to 20 m

Without wire end
ferrule

6 mm

2

(AWG 10)

1.2 ... 1.5 Nm

(10.6 ... 13.3 lb-in)

5 mm for screw
connection

10 mm for spring
connection

With insulated wire
end ferrule

> 20 m

Without wire end
ferrule

10 mm

2

(AWG 8)

With insulated wire
end ferrule
Use pin-end
connectors for
wiring!
