Installation check

5



58

EDKCSEK002 DE/EN/FR 2.0

5

Installation check

After completing the installation, check ...

ƒ

the wiring for completeness, short circuit, and earth fault.

ƒ

the power connection (X23):

–

polarity of the DC-bus voltage supply via terminals +UG, -UG

ƒ

the control connection (X26):

–

short-circuiting of the charging current limitation depending on the
power supply module connected.



Note!

In the next step the drive system is commissioned.
Relevant information can be found in the detailed documentation
of the power supply modules and axis modules connected.
