Function library LenzeDrive.lib
Appendix
3−3
L
LenzeDrive.lib EN 1.7
Code Info IMPORTANT Possible settings LCD Code Info IMPORTANT
Choice Lenze
LCD
C0329 byPCharacteristic 0 Activate adaptation of L_PCTRL1 ^ 2−79
0 no
1 External
Vp
2 Setpoint
3 Ctrl
diff
no process controller adaptation
external via input
Adaptation via setpoint
Adaptation via control difference ^ 2−79
C0332 PCTRLdnTir 0.000 0.000 {0.001 sec} 999.900 Acceleration time T
ir
of L_PCTRL1
·
Referred to the setpoint change
0 ... 100 %.
^ 2−79
C0333 dnTif 0.000 0.000 {0.001 sec} 999.900 Deceleration time T
ir
of L_PCTRL1
·
Referred to the setpoint change
0 ... 100 %.
^ 2−79
C0337 bBiUnipolar 0 0 bipolar
1 unipolar Effective range bipolar/unipolar of
L_PCTRL1 ^ 2−79
C0338 byFunction 1 0 OUT = nIn1_a
1 nIn1_a + nIn2_a
2 nIn1_a − nIn2_a
3 nIn1_a * nIn2_a
4 nIn1_a / nIn2_a
5 nIn1_a / (100 − nIn2_a)
Function arithmetic block L_ARIT1
·
Combines inputs nIn1_a and
nIn2_a .
^ 2−11
C0560
1
...
14
15
anSollW1
...
anSollW14
anSollW15 0.00
...
0.00
0.00
−199.99 {0.01 %} 199.99 Fixed setpoints for L_FIXSET1 ^ 2−2
C0600 byFunction 1 0 OUT = nIn1_a
1 nIn1_a + nIn2_a
2 nIn1_a − nIn2_a
3 nIn1_a * nIn2_a
4 nIn1_a / nIn2_a
5 nIn1_a / (100 − nIn2_a)
Function arithmetic block L_ARIT2
·
Combines inputs nIn1_a and
nIn2_a .
^ 2−11
C0620 nGain 1.00 −10.00 {0.01} 10.00 Gain for dead−band component L_DB1 ^ 2−20
C0621 nDeadBand 1.00 0.00 {0.01 %} 100.00 Dead−band of DB1 ^ 2−20
C0630 nMaxLimit 100.00 −199.99 {0.01 %} 199.99 Upper limit of limiter L_LIM1 ^ 2−22
C0631 nMinLimit −100.0 −199.99 {0.01 %} 199.99 Upper limit of limiter L_LIM1 ^ 2−22
C0640 nDelayTime 20.00 0.01 {0.01 sec} 50.00 Time constant of L_PT1_1 ^ 2−23
C0650 nGain 1.00 −320.00 {0.01} 320.00 Gain of L−DT1_1 ^ 2−21
C0651 nDelayTime 1.000 0.005 {0.001 sec} 5.000 Time constant of L_DT1_1 ^ 2−21
C0653 bySensibility 1 1 15 Bit
2 14 Bit
3 13 Bit
4 12 Bit
5 11 Bit
6 10 bit
7 9 Bit
Input sensitivity of L_DT1_1 ^ 2−21
C0655 nNumerator 1 −32767 {1} 32767 Numerator for L_CONV5 ^ 2−49
C0656 nDenominator 1 1 {1} 32767 Denominator for L_CONV5 ^ 2−49
C0671 dnTir 0.000 0.000 {0.01 sec} 999.900 Acceleration time T
ir
of ramp generator
L_RFG1
^ 2−24
C0672 dnTif 0.000 0.000 {0.01 sec} 999.900 Deceleration time T
if
of L_RFG1 ^ 2−24
C0680 byFunction 6 1 nIn1 = nIn2
2 nIn1 > nIn2
3 nIn1 < nIn2
4 |nIn1| = |nIn2|
5 |nIn1| > |nIn2|
6 |nIn1| < |nIn2|
Function comparator L_CMP1
·
Compares the inputs nIn1 and nIn2
^ 2−13
C0681 nHysteresis 1.00 0.00 {0.01 %} 100.00 % Hysteresis of L_CMP1 ^ 2−13
C0682 nWindow 1.00 0.00 {0.01 %} 100.00 % Window of L_CMP1 ^ 2−13
