2.4.5 Division (L_PHDIV)
Function library LenzeDrive.lib
Processing of phase−angle signals
2−42
L
LenzeDrive.lib EN 1.7
2.4.5 Division (L_PHDIV)
This FB divides or multiplies phase−angle signals in binary−exponent format.
1
2 b y D i v i s i o n
d n I n _ p d n O u t _ p
L _ P H D I V
± 2 3 1
R e v o l u t i o n
Fig. 2−53 Division (L_PHDIV)
VariableName DataType SignalType VariableType Note
dnIn_p Double integer position VAR_INPUT
dnOut_p Double integer position VAR_OUTPUT 65536 inc = 1 encoder revlution
byDivision Short Integer VAR CONSTANT RETAIN Exponent of the divisor
Parameter codes of the instances
VariableName L_PHDIV1 SettingRange Lenze
byDivision C0995 −31 ... 31 0
Function
You can calculate the result of the arithmetical function according to the formula:
dnOut_p +
dnIn_p
2 byDivision
·
Positive values in byDivision result in a division.
·
Negative values in byDivision result in a multiplication.
·
The output signal is limited to ±2 31 −1 encoder turns.
– The output signal cannot exceed this limit value.
