2.7.4 Speed preconditioning (L_NSET)
2−75
L
LenzeDrive.lib EN 1.7
2.7.4.2 JOG setpoints
JOG setpoints are fixed values that are stored under anJogSetValue[0] ... anJogSetValue[14] in the
memory.
·
The JOG values can be called up from the memory by bJog1_b ... bJog8_b.
– These inputs are binary coded, so that 15 JOG values can be called.
·
The decoding for the enabling of the JOG values (calling from the memory) is carried out
according to the following table:
Main setpoint of bJog8_b bJog4_b bJog2_b bJog1_b
nNSet_a 0 0 0 0
anJogSetValue[0] 0 0 0 1
anJogSetValue[1] 0 0 1 0
anJogSetValue[2] 0 0 1 1
anJogSetValue[3] 0 1 0 0
anJogSetValue[4] 0 1 0 1
anJogSetValue[5] 0 1 1 0
anJogSetValue[6] 0 1 1 1
anJogSetValue[7] 1 0 0 0
anJogSetValue[8] 1 0 0 1
anJogSetValue[9] 1 0 1 0
anJogSetValue[10] 1 0 1 1
anJogSetValue[11] 1 1 0 0
anJogSetValue[12] 1 1 0 1
anJogSetValue[13] 1 1 1 0
anJogSetValue[14] 1 1 1 1
0 = FALSE
1 = TRUE
·
The number of VAR_INPUT variables to be assigned depends on the number of JOG setpoints
required. A maximum of 4 VAR_INPUT variables and thus 15 selection possibilities are
available.
Number of the required JOG setpoints Number of VAR_INPUT (bJog1_b ... bJog8_b) to be assigned
1 at least 1
1 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
2.7.4.3 Setpoint inversion
The output signal of the JOG function is led via an inverter.
The sign of the setpoint is inverted, when bNSetInv_b switches = TRUE .
