Function library LenzeDrive.lib
Appendix
3−1
L
LenzeDrive.lib EN 1.7
3 Appendix
3.1 Code table
How to read the code table:
Column Abbreviation Meaning
Code Cxxxx
1
2
…
Code Cxxxx
Subcode 1 of code Cxxxx
Subcode 2 of code Cxxxx
…
[Cxxxx] Parameter value of the code can only be modified when the controller is inhibited.
LCD Keypad LCD
·
DIS: Display only
·
All others are parameter values.
Lenze Lenze setting of the code
The column IMPORTANT contains further information.
Choice 1 {1 %} 99 Minimum value {Smallest step/unit} Maximum value
IMPORTANT − Additional, important explanation of the code
Code LCD Possible settings IMPORTANT Info
Lenze Choice
C0012 dnTir 0.000 0.000 {0.001 s} 999.900 Acceleration time T
ir
for the main
setpoint of L_NSET1
·
Related to the speed change
0 ... n
max
.
^ 2−73
C0013 dnTif 0.000 0.000 {0.001 sec} 999.900 Deceleration time T
if
for the main
setpoint of L_NSET1
·
Related to the speed change
n
max
... 0.
^ 2−73
C0039
1
...
14
15
anJOGSetValue1
...
anJOGSetValue14
anJOGSetValue15 0.00
...
0.00
0.00
−199.99 {0.01} 199.99 Fixed speeds (JOG setpoints) can be
selected for L_NSET1 using digital
inputs.
^ 2−73
C0101
1
2
...
15
adnTir1
adnTir2
...
adnTir15 0.000
0.000
...
0.000
0.000 {0.001 sec} 999.900 Additional acceleration times T
ir
for the
main setpoint of L_NSET1
·
Related to the speed change
0 ... n
max
.
^ 2−73
C0103
1
2
...
15
adnTif1
adnTif2
...
adnTif15 0.000
0.000
...
0.000
0.000 {0.001 sec} 999.900 Additional deceleration times T
if
for the
main setpoint of L_NSET1
·
Related to the speed change
n
max
... 0.
^ 2−73
C0134 bSShapeActive Ramp generator characteristic for the
main setpoint of L_NSET1 ^ 2−73
0 0 linear
1 S−shaped Linear S−shaped ^ 2−73
C0182 nTiSShaped 20.00 0.01 sec {0.01 sec} 50.00 sec T
i
−time of the S−curve ramp generator
for L_NSET1
Determines the S curve
·
Low values åsmall S−rounding
·
High values ålarge S−rounding
^ 2−73
