Function library LenzeDrive.lib
General signal processing
2.1.1 Programming fixed setpoints (L_FIXSET)
2−3
L
LenzeDrive.lib EN 1.7
2.1.1.1 Enable of the fixed setpoints
Number of required fixed setpoints Number of the inputs to be assigned
1 at least 1
1 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
Decoding table of the binary input signals:
Output signal
nOut_a = 1st input
bIn1_b
2nd input
bIn2_b
3rd input
bIn3_b
4th input
bIn4_b
nAin_a 0 0 0 0
anSollW1 1 0 0 0
anSollW2 0 1 0 0
anSollW3 1 1 0 0
anSollW4 0 0 1 0
anSollW5 1 0 1 0
anSollW6 0 1 1 0
anSollW7 1 1 1 0
anSollW8 0 0 0 1
anSollW9 1 0 0 1
anSollW10 0 1 0 1
anSollW11 1 1 0 1
anSollW12 0 0 1 1
anSollW13 1 0 1 1
anSollW14 0 1 1 1
anSollW15 1 1 1 1
0 = FALSE
1 = TRUE
