Parameter setting
Digital inputs and outputs
Description of the objects
7

86 KHB 13.0003-EN 2.0
Characteristics Possible settings Name Index
Description Selection Lenze
2005
h
0 local_output_
function
0 -128 {1} 127 VAR INT8 RW —
Digital output can be
parameterised by the user.
Value Function Active
-128 ... -17 Reserved
-16 Reference set Low
-15 ... -14 Reserved
-13 Stopover Low
-12 Motor
deenergised
Low
-11 Controller error Low
-10 Reserved
-9 Drive in standstill Low
-8 Reserved
-7 Homing active Low
-6 ... -5 Reserved
-4 Setpoint reached Low
-3 Traversing request
is being processed Low
-2 Fault
Low
-1 Warning
0 No function
1 Warning High
2 Fault High
3 Traversing request
is being processed High
4 Setpoint reached High
5 ... 6 Reserved
7 Homing active High
8 Reserved
9 Drive in standstill High
10 Reserved
11 Controller error High
12 Motor
deenergised
High
13 Stopover
14 ... 15 Reserved
16 Reference set High
17 ... 127 Reserved
