Appendix
Index table
10

151 KHB 13.0003-EN 2.0
Characteristics Possible settings Name Index
Description Selection Lenze
60FE
h
Digital_outputs
0 number_of_
supported_entries
00
h
{1
h
} 02
h VAR
UINT8 RO —
Maximally supported
subindices.
02
h
Three subindices are
supported.
1 digital_outputs_
data
0 00000000
h
{1
h
} FFFFFFFF
h VAR
UINT3
2
RW MAP
Bit No. Digital output Activating or deactivating
special functionalities or
outputs.
With bit 0, you can, for
instance, activate or
deactivate the brake.
0 Brake
1 ... 15 Reserved
16 DOUT0
17 Neg. limit switch
18 Pos. limit switch
19 Reference switch
20 Quick stop
17 ... 31 Reserved
2 digital_outputs_
mask
0 0 {1} 1 VAR UINT3
2
RW MAP
Defining a mask to ensure
that an output is not
activated when this is not
desired.
0 Output is not selected
1 Output is selected
60FF
h
0 target_velocity 0 -2 31 {1 rpm} 2 31 -1 VAR INT32 RW MAP
Setting the speed setpoint.
