Appendix

Index table

10



152

KHB 13.0003-EN 2.0

Characteristics

Possible settings

Name

Index

Description

Selection

Lenze

6410

h

Motor_data

1 resolver_offset

1

0

{1 inc}

4096

VAR

UINT1

6

RW

—

Setting the resolver offset.

2 number_of_pole_

pairs

2

1

{1}

13

VAR

UINT1

6

RW

—

Setting the pole pair

number.

Bit No.

Meaning

0 ... 3

Pole pair number

4

Reversal of direction of resolver

3 braking _times

{1 ms}

VAR

UINT3

2

RW

—

Setting the

disengagement and

engagement time of the

brake.

Bit No.

Meaning

0 ... 15

Disengagement time

16 ... 31 Engagement time

4 brake_voltage

001A0012

{1 V}

VAR

UINT3

2

RW

—

Setting the value range for

the brake voltage.

Bit No.

Meaning

0 ... 15

Minimum limit value (18 ... 22 V)

16 ... 31 Maximum limit value (26 ... 32 V)

6510

h

Drive_data

0 number_of_

supported_entries

00

h

{1

h

}

03

h VAR

UINT8

RO

—

Maximally supported

subindices.

03

h

Four subindices are

supported.

1 identification

VAR

UINT3

2

RO

—

Reading the identification.

2 serial_number

VAR

UINT3

2

RO

—

Reading the serial number.

3 operating_minutes

VAR

UINT3

2

RO

—

Reading the operating

minutes.
