Appendix
Index table
10
120
KHB 13.0003-EN 2.0
Characteristics
Possible settings
Name
Index
Description
Selection
Lenze
1003
h
Pre_defined_error_
field
0 number_of_errors
00
h
{1
h
}
FF
h
UINT8
RW
—
Reading the number of
error messages saved.
00
h
Deleting the history buffer
by writing the value 00
h
.
After an error, the error
must be acknowledged to
activate the power stage.
1 standard_error_
field_0
—
UINT3
2
RO
—
Reading the last error
message.
Bit
31 ... 24
23 ... 16 15 ... 8
7 ... 0
00
00
23
00
Motor deenergised due to
overcurrent
00
00
32
10
DC-bus voltage > 400 V
00
00
32
20
DC-bus voltage < 180 V
00
00
33
20
20 V > brake
voltage > 28 V
00
00
42
10
Power stage
overtemperature
00
00
43
10
Motor overtemperature
00
00
63
20
Driving program, system
parameters
00
00
71
21
Drive inhibited
00
00
90
00
Quick stop
00
00
FF
00
Homing
...
4 standard_error_
field_3
—
UINT3
2
RO
—
Reading the error
message.
1005
h
0 COB-ID_sync_
message
00000080
h
00000080
h
{1
h
}
80000080
h VAR
UINT3
2
RW
—
The identifier of the
synchronisation object is
80
h.
Determining whether the
controller is to receive or
send synchronisation
messages.
Bit No.
Value
0 - 10
X
11-bit identifier.
11 - 28
0
The extended identifier
(bit 29) is not supported.
Every bit in this range
must be set to ”0”.
29
0
30
0
Controller does not
generate sync telegrams.
1
Controller generates sync
telegrams.
31
X
As you choose
