Page 49

Lenze · EMF2180IB communication module (EthernetCAN) · Communication Manual · DMS 5.0 EN · 07/2014 · TD17
49
7
Data transfer
7.3
Data transfer via Ethernet
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.3
Data transfer via Ethernet
The Engineering PC and the communication module communicate via a proprietary protocol which
is based on TCP/IP. The port number '22080' is used for the communication module.
The port number may have to be cleared if a firewall or something similar is used.
Port '3677' is used to search for fieldbus nodes.
Port '80' is required to operate the web server.
Tip!
The search via Ethernet is only possible within one network. The frames are not
transmitted via routers.
Ethernet communication manual
Here you'll find some detailed information relating to the Ethernet data frame structure.
