6 Commissioning
6.1 Commissioning with the Lenze "System bus configurator"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.1.3 After completing the configuration
Communication with Lenze Engineering tools
When the configuration of the communication module has been completed successfully, the Lenze
Engineering tools can communicate via the communication module. The Lenze Engineering tools
only carry out the selection of the bus system to be used.
All system bus-specific settings as well as the selection of the communication module are
exclusively carried out via the "System bus configurator".
Communication with nodes
If the communication module can communicate successfully with the corresponding nodes, the
CAN node addresses of the nodes found are listed in the Device status field.
The communication module itself answers with its CAN node address or with "0" if it doesn't have
a CAN node address (depending on the setting in C0350 ). The data frames for communication with
the communication module itself are not visible on the CAN bus.
Communication failed
If there is no communication with the nodes, a corresponding error message is output.

Note!
For some older program versions of the Lenze Engineering tools, settings for "Interrupt"
and "I/O address" can still be made, which, for the EMF2180IB communication module,
are irrelevant.
