Parameter numbers
Data type - IO settings (PNU 102)
8

64 K-HB 13.0001-EN 2.1
PNU Subindex Description
Possible settings
Data type Lenze Selection
102 1 ”Quick stop” input is active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [12]
1 Low
”Start” input is active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [13]
1 Low
2 Output mask: Status word & V2
(Object for drive with I/O input
functionality. Not for devices
with local CAN)
Bit [0]
3 Fluxxtorque output mask:
Status word & V2
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
Bit [0]
4 Output is active:
(Object for drive with I/O input
functionality. Not for devices
with local CAN)
0 High
Bit [0]
1 Low
Output is active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [1]
1 Low
”Trouble” output is active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [2]
1 Low
”Data record is being
processed” output is active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [3]
1 Low
”Setpoint reached” output is
active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [4]
1 Low
Debounce time for start input [ms] Bit [15 ... 8]
Tab. 32 Data type - I/O settings (PNU 102)
