Page 56: 11 selector switch - status word bit 12 (pnu 940), Parameter numbers
Parameter numbers
Explanation of the parameter numbers
Selector switch - status word bit 11 (PNU 939)
8
56
K-HB 13.0001-EN 2.1
Description
Meaning
Selection
0x8049 Inverter input Stop is activated /
deactivated
0x804a Inverter input Limit left is activated /
deactivated
0x804b Inverter input Limit right is activated /
deactivated
0x804c Inverter input Quick stop is activated /
deactivated
0x804d Inverter input Input is activated /
deactivated
8.1.10
Selector switch - status word bit 11 (PNU 939)
PNU
Subindex Description
Possible settings
Data type
Lenze
Selection
939
0
Selector switch - status word
bit 11
Unsigned 16
1
0x804d
Selection Meaning
Description
1 Home position is set / no home
position is set
Here the bit value ”1” of the status word indicates a set home
position, the bit value ”0” indicates that no home position is set.
0x8000
...
0x804d
See PNU 938
8.1.11
Selector switch - status word bit 12 (PNU 940)
PNU
Subindex Description
Possible settings
Data type
Lenze
Selection
940
0
Selector switch - status word
bit 12
Unsigned 16
1
0x804d
Selection Meaning
Description
1 Setpoint acknowledgement
(edge)
Here the status word, bit 12, is set to its original function ”setpoint
acknowledgement”. This bit reflects bit 6 of the control word
which activates a positioning driving request by an edge.
0x8000
...
0x804d
See PNU 938
